d.052 Motor OL (Motor overload)
Motor overload level (100% = alarm threshold).
d.053 Brake res OL (Brake resistror overload)
Braking resistor overload level (100%=alarm thr).
d.054 Reserved
Code LCD display [Code] & LCD select. Default MIN MAX Unit Variation IPA
d.050 Heatsink temp °C 1 010
d.051 Drive OL % 0.1 011
d.052 Motor OL % 0.1 012
d.053 Brake res OL % 0.1 013
d.054 Reserved 058
Inputs/Outputs
d.100 Dig inp status (Digital inputs status)
Status of the digital inputs acquired by the drive. Each of the inputs can come either from regulation board
terminal or from serial line. See figure 7.4.5 .
According to the type of keypad in use, the status of digital inputs will be displayed as follows:
Reset
Hz A VPrg Rev Fwd
Prg
Dig inp status
Digital input1=ON
Digital input5=ON
___5___1
Hz A VPrg Rev Fwd
.I. .I.
Digital input2=OFF
Digital input1=ON
Digital input3=OFF
Digital input4=OFF
Digital input8=OFF
Digital input7=OFF
Digital input6=OFF
Digital input5=ON
d.101 Term inp status (Terminal inputs status)
Status of the digital inputs terminal of the drive regulation board.
See example d.100
d.102 Vir dig inp stat (Virtual digital inputs status)
Status of the virtual digital inputs received by serial link or field bus card, by writing parameter H.000.
See example d.100
