Commissioning
6.5 Other device functions
3RW44 soft starters
110 Manual, 03/2017, NEB535219502000/RS-AB/008
Motor control (assigning control priority)
Figure 6-1 Motor control
The "Standard control" menu item specifies which control device should be given control
priority when the control supply voltage is applied.
When the PROFIBUS/PROFINET communication module is activated, the setting is
changed to "Automatic/None".
