General technical data
11.1 Menu structure
3RW44 soft starters
244 Manual, 03/2017, NEB535219502000/RS-AB/008
Menu: status display
Inputs
Status - inputs
Input 1 - action
No action
Manual mode local
Emergency start
Slow speed
Quick stop
Trip reset
Motor CW PS1
Motor CCW PS1
*)
Motor CW PS2
Motor CCW PS2
*)
Motor CW PS3
Motor CCW PS3
*)
Input 2 - action [...]
Input 3 - action [...]
Input 4 - action [...]
Outputs
Status - outputs
Output 1 - action
No action
PIQ output 1
PIQ output 2
Input 1
Input 2
Input 3
Input 4
Startup
Operation/bypass
Run down
ON time
Command motor On
DC braking contactor
Group warning
Group fault
Bus fault
Device fault
Power on
Ready to start
Output 2 - action [...]
Output 3 - action [...]
Output 4 - action [...]
Article number
Firmware information
Version
Date
*)
Only possible in combination with slow speed
