03/2013 5 Statistics/export
5.1 Multi-machine views
© Siemens AG 2006-2012 All Rights Reserved
SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
5-241
Fig. 5-7: Machine selection
Function Description Type
A yellow icon indicates an active filter. The filter
conditions are displayed provided they fit in the
line.
DISPLAY
Time period In addition to being set over the entire period, the
filter can also be set with retrospective effect from
the current date back to the last day, last week, or
last months.
SELECTION
DISPLAY
To search for events after they have occurred,
you can restrict the time period for the display of
events with a calendar function.
SELECTION
DISPLAY
Filtering Events are displayed according to the selected
time frame.
ACTION
Number of
lines
The number in the display indicates the number of
lines per screen that can be shown in this menu.
You can select up to 200 lines. A scroll bar will
then be displayed on the screen.
DISPLAY
SELECTION
Control
monitor
Events are sorted by the linked control monitors in
descending order over all selected machines.
Click on the "+" icon to display the machines in
which the control monitor is used.
This display corresponds to the display described
above for machines with events.
Within this selection, you can click the "Folder"
icon to branch directly to the machine events to
see this particular machine without changing
filters or filter period.
DISPLAY
SELECTION
ACTION
Prio 0 to 5 Total number of events with the specific priority
assigned by the user for the control monitor.
DISPLAY
