Operating Manual of FC18 Controller
Page: 15/63
until master is reset.
⑤ Interlocking panel
The interlocking panel has 8 output channels. Each channel has indicators to indicate trouble, activation and
confirmation status. Each channel can be controlled manually with Activation/Deactivation button. Only level 2&3 user
can access. Press the button to activate it and press it again to deactivate it, so on and so forth.
¹ Trouble: On when there is trouble; Off when trouble is solved.
¹ Activation: On when output channel is activated; Flashing when there's no confirmation; Off when the output
channel resume normal.
¹ Confirmation: On when confirmation is received; Off when confirmation signal disappears.
Note: FC1840C doesn’t have interlocking panel and printer.
