Operating Manual of FC18 Controller
Page: 26/63
9. REAL-TIME QUERY
FC18 fire alarm controller (interlocking) contains ten types of real-time events:
Table 3-2
Types of real-time events Priority
Fire alarm/activation 1
Supervision 2
Disable 3
Trouble 4
Test 5
Walk-test 5
Locate 5
Unconfigure equipment 6
Unknown equipment 7
Inconsistent equipment 8
Exchange equipment 9
Unconfigure equipment: Equipments not on the engineering document list.
Unknown equipment: Equipments not listed by Table 1-2.
Inconsistent equipment: The type of installed equipment on site is inconsistent with engineering document.
Exchange equipment: Dirty smoke detector.
Steps:
1. Press Menu” to browse the main menu. (Fig. 9-1)
Main menu displayed.
2. Press to select an event type to query then press “OK”.
All the events meeting the requirements will be displayed in the window. Use
” /”to browse items.
When an event is selected, press “” to pop out a shortcut menu (Fig. 9-2). All
operable items will be listed according to user’s level. Use ” / ” to select
an operation then press “OK” to take the operation.
Note:
“0001”: Order of an event
“COMM trouble”: Type of an event
“2008-08-08 10:10:10”: Date and time when an event takes place
Interlocking line / 01.0005”: Text message and equipment address of an
event
“Interlocking group”: text message of the group which this interlocking
equipment belongs to. (If the equipment does not belong to any group,
only text message of the event and equipment address are displayed.)
SIEMENS
<2008-08-08 08:08:08>
System Normal
SIEMENS Building
Event Brow Help Login
Alarm & active
Trouble
Supervision
Disable
Test
Walk-Test
Locate
Alarm & active
Fig. 9-1
0002 COMM trouble 2008-08-08 10:10:10
Interlocking Line / 01.005
Trouble
0001 Other 2008-08-08 10:10:08
Room 1008, Building 1 / 01.001.291
Property
History
Disable
Test
Property
Fig. 9-2
