Operating Manual of FC18 Controller
Page: 5/63
3. DIMENSIONS
Fig. 1-1 FC18 Appearance Fig. 1-2 FC18 Dimensions (mm)
4. COMPATIBLE LIST
No. Type Description
1. FDT181 Addressable heat detector
2. FDO181 Addressable smoke detector
3. FDM181 Addressable manual call point
4. FDCI181-2 Addressable input module
5. FDCIO181-2 Addressable input/output module
6. FDCI181-1 Addressable input module
7. FDCIO181-1 Addressable input/output module
8. FT1810 Addressable floor repeater display
9. FDCL181 Isolator
10. FT1811 Addressable mimic drive
11. FTM1811 Addressable mimic display board
12. FDCAI181 Addressable alarm indicator
