Siemens FC18 User Manual

Operating Manual of FC18 Controller
Page: 53/63
No. Failure phenomenon Cause analysis Solving Method
Power trouble;
10.
Line card failure
Engineer software configuration not in line
with actual equipment;
Address not set for circuit card or not in line
with software address;
Circuit card or part of it damage;
Error of FDnet signal line, power line
Severe damage of spot component;
Change the software
configuration;
Change the address
configuration;
Change circuit card;
Check communication, power
lines
Change damaged spot
components;
11.
Spot component failure
Wiring trouble;
Engineer software configuration not in line
with actual equipment;
Address not set for spot component or not in
line with software address;
Spot component damage;
Examine wire connections;
Change configuration;
Change software
configuration;
Change damaged spot
components;
12.
Automatic interlocking
failure
Controller, interlocking panel not in automatic
status;
interlocking relation not set for software, or
interlocking relation error;
interlocking equipment damage;
Power, interlocking lines damage;
Change configuration;
Set/change interlocking
relation;
Change damaged spot
components;
Examine wire connections;
13.
Manual control failure
Not enough operation level;
Controller, interlocking panel not in manual
status;
interlocking equipment damage;
Power, interlocking lines damage;
Login higher operation level;
Change configuration;
Change damaged spot
component;
Examine wire connections;
14.
Isolation, open failure
Not enough operation level;
Operation method trouble;
Operation panel damage;
Main board damage;
Login higher operation level;
Operate correctly;
Change operation panel;
Change main board;
15.
Test, manually relieve
failure
Not enough operation level;
Operation method trouble;
CPU damage;
Login higher operation level;
Operate correctly;
Change CPU;
16.
Test, manually relieve
failure
Not enough operation level;
Operation method trouble;
CPU damage;
Login higher operation level;
Operate correctly;
Change CPU;
17.
Display failure of fire
alarm, activation up,
error
Software trouble;
CPU damage;
Update software;
Change CPU;
18.
Query history event
failure
Operation method trouble;
Part of main board damage;
Operate correctly;
Change main board;
19.
Spot program
(correction) failure
Not enough operation level;
Operation method trouble;
CPU damage;
Login higher operation level;
Operate correctly;
Change CPU;
20.
Printer open/close failure
Not enough operation level;
Operation method trouble;
Power, signal lines damage;
Software configuration trouble;
Printer damage;
Login higher operation level;
Operate correctly;
Connect wires correctly;
Update software;
Change printer;
21.
Other operations of
controller failure
Not enough operation level;
Operation method trouble;
Software lost or error;
Some hardware damage;
Login higher operation level;
Operate correctly;
Update software;
Change corresponding
hardware;
