Operating Manual of FC18 Controller
Page: 7/63
Fig. 1-4 Internal structure
Po
wer supply
Terminal board
B
attery
Line card 2
Line card 1
LED screen
Keyboard 2
Interlocking panel
Pinter
Keyboard 1
Main board
CPU board
