Siemens G120P

Commissioning
3
A
dditional important parameters
29
Siemens AG
CM2G5111en
2014-05-16
Additional important parameters
Parameter Factory setting Function
p0601 0 Motor temperature sensor type:
0: No sensor
1: PTC warning & timer
2: KTY84
4: Bimetallic NC contact alarm & timer
p0730 r52.3 Digital output 0: Fault active
p0731 r52.7 Digital output 1: Alarm active
p0732 r52.2 Digital output 2: Operation enabled. Motor in operation.
p0748 000 Invert digital outputs (0 = do not invert, 1 = invert)
Bit 0: DO 0
Bit 1: DO 1
Bit 2: DO 2
r0755[0..3] - Analog inputs, actual value in percent
p0756 [0] - AI 0 (0-4) 0: Unipolar voltage input (0 V...10 V)
1: Unipolar voltage input monitored (2 V... 10 V)
2: Unipolar current input (0 mA…20 mA)
3: Unipolar current input monitored (4 mA…20 mA)
4: Bipolar voltage input (-10 V...10 V)
6: LG-Ni1000 temperature sensor (-50 °C…150 °C)
7: PT1000 temperature sensor (-50…250 °C)
8: No sensor connected
p0756 [1] - AI 1 (0-4)
p0756 [2] - AI 2 (2-3, 6-8)
p0756 [3] - AI 3 (6-8)
p0771[0] - AO 0 Important status signals:
0: Analog output locked
21: Speed actual value
24: Output frequency smoothed
25: Output voltage smoothed
26: DC link voltage smoothed
27: Actual current value (smoothed absolute value)
p0771[1] - AO 1
p0776[0,
1]
- Analog outputs, type
0: Current output (0 mA...20 mA)
1: Voltage output (0 V...10 V)
2: Current output (4 mA...20 mA)
p0840 r0722.0 ON/OFF1 signal source
p0852 1 Enable operation
Is used to let the motor coast to a standstill if the ON command is
enabled. Example: P0852 = r0722.0.
p1000 2 Speed setpoint selection
2 = Analog setpoint
3 = Fixed speed
6 = Fieldbus.
For further values, see the List Manual
p1082 1500 rpm Maximum speed
The reference speed (p2000) must also be taken into consideration.
p1113 r722.1 Invert direction of rotation
p1200 0 Flying restart selection:
0: Flying restart inactive
1: Flying restart always active (start in setpoint direction)
4: Flying restart always active (start only in setpoint direction)
p1210 0 Automatic restart:
0: Disables automatic restart
3.6
