Siemens G120P

7
Appendix
Commissioning report
58
Siemens AG CM2G5111en
2014-05-16
Appendix
Commissioning report
Parameter Function Factory setting Setting
P0970 Restoring the factory setting -
P1300 Control type 2 (V/f parabolic)
P0100 Motor standard 0 (IEC motor)
P0304 Rated motor voltage [V]
P0305 Rated motor current [A]
P0307 Motor power [kW]
P0311 Rated motor speed [rpm]
P1900 Motor data identification selection 0
P0015 Macro parameter 12
P1080 Minimum speed [rpm] 0
P1120 Ramp-up time [s] 10
P1121 Ramp-down time [s] 30
P0601 Motor temperature sensor 0 (no sensor)
P0731 (0) Digital output function 0 52.3 (Fault)
P0732 (0) Digital output function 1 52.7 (Alarm)
P0732 (0) Digital output function 2 52.3 (Operation)
P0757 (0) x1 value for ADC scaling [V / mA] 0
P0758 (0) y1 value for ADC scaling [%] 0
P1082 Maximum speed [rpm] 1500
P1200 Flying restart operating mode 0 (flying restart inactive)
P1210 Automatic Restart 0 (disabled)
P1211 No. of start attempts 3
P1212 Time until the first restart [s] 1
P1213[0] Monitoring time for restart [s] 60
P1213[1] Time to reset the start counter [s] 0
P1240 Configuration of the Vdc controller 1
P1820 Reverse output phase sequence 0
P2000 Reference speed [rpm] 1500
Available documentation
Title Description Source/Document ID
Getting Started Design, installation, commissioning and
troubleshooting the SINAMICS G120P.
A5E03653438A AA
Getting Started Guide
Power Module PM230
Hardware IP55
Quick guide with dimensions and design
and installation notes.
A5E02923634A
Getting Started Guide
Power Module PM230
Hardware IP20
Quick guide with dimensions and design
and installation notes.
A5E03460238A
Hardware Installation Guide with all the information needed to A5E02923635A AA
