Open the "Axis" selection box using the <INSERT> key, navigate to the
desired axis, and press the <INPUT> key.
Selecting an axis also activates the handwheel (e.g., "X" is assigned to
handwheel no. 1 and is activated immediately).
6. Press the "Handwheel" softkey again.
- OR -
Press the "Back" softkey.
The "Handwheel" window closes.
Deactivate handwheel
1. Position the cursor on the handwheel whose assignment you wish to
cancel (e.g. No. 1).
2. Press the softkey for the assigned axis again (e.g. "X").
- OR -
Open the "Axis" selection box using the <INSERT> key, navigate to the
empty field, and press the <INPUT> key.
Clearing an axis selection also clears the handwheel selection (e.g., "X"
is cleared for handwheel no. 1 and is no longer active).
Setting up the machine
4.11 Handwheel assignment
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 157
