16.2
Measuring the tool
All the options of the
manual and automatic measurement are available to determine
the tool
offset data (see also Section "Measure tool (Page 100)").
Procedure
1.
"Manual Machine" is active.
2.
Press the "Meas. tool" softkey.
3.
Select the
the
required
measuring function
in
the
vertical softkey
bar
and
press the appropriate softkey.
Working with Manual Machine
16.2 Measuring the tool
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
833
