7.7.2 Simulating the program block by block
You have the capability of controlling the program execution during the simulation, i.e. to
execute a program, e.g. program block by program block.
Procedure
1. Simulation is started.
2. Press the "Program control" and "Single block" softkeys.
3. Press the "Back" and "Start SBL" softkeys.
The pending program block is simulated and then stops.
4. Press "Start SBL" as many times as you want to simulate a single program
block.
5. Press the "Program control" and the "Single block" softkeys to exist the
single block mode.
Switching a single block on and off
Press the <CTRL> and <S> keys simultaneously to enable and disable the
single block mode.
Simulating machining
7.7 Program control during the simulation
Milling
288 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
