Block number, or line number
●
Remain program run throughs (only for several program run throughs)
Precondition
A program must be selected for execution in "AUTO" mode.
Procedure
Press the "Program levels" softkey.
The "Program levels" window appears.
Machining the workpiece
6.4 Displaying the current program block
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
197
196
198
