7.
Continue programming up to
the point where
you want to repeat the
pro‐
gram blocks.
8.
Press the "Various" and "Repeat progr." softkeys.
9.
Enter the names of the start and end markers and the number of times
the blocks are to be repeated.
10.
Press the "Accept" softkey.
The marked program blocks are repeated.
Creating a ShopMill program
9.11 Repeating program blocks
Milling
340
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
