Parameter Description Unit
Chamfer FS Transition to following element - chamfer mm
Additional commands Additional G code commands
Contour element "Straight line, e.g. XY"
Parameter Description Unit
X End point X (abs or inc) mm
Y End point Y (abs or inc) mm
L Length mm
α1 Starting angle e.g. to the X axis Degrees
α2 Angle to the preceding element Degrees
Transition to next ele‐
ment
Type of transition
● Radius
● Chamfer
Radius R Transition to following element - radius mm
Chamfer FS Transition to following element - chamfer mm
Additional commands Additional G code commands
Contour element "Circle"
Parameter Description Unit
Direction of rotation
● Clockwise direction of rotation
● Counterclockwise direction of rotation
R Radius mm
e.g. X End point X (abs or inc) mm
e.g. Y End point Y (abs or inc) mm
e.g. I Circle center point I (abs or inc) mm
e.g. J Circle center point J (abs or inc) mm
α1 Starting angle to X axis Degrees
α2 Angle to the preceding element Degrees
β1 End angle to Z axis Degrees
β2 Angle of opening Degrees
Transition to next ele‐
ment
Type of transition
● Radius
● Chamfer
Radius R Transition to following element - radius mm
Chamfer FS Transition to following element - chamfer mm
Additional commands Additional G code commands
Programming technological functions (cycles)
10.3 Contour milling
Milling
488 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
