5. In the window "Settings for Multi-Channel View" in the selection
box "View", select the required entry (e.g. "2 channels") and define
the channels as well as the sequence in which they are to be dis‐
played.
In the basic screen for the "AUTO", "MDA" and JOG" operating
modes, the upper window of the left-hand and right-hand channel
columns are occupied by the actual value window.
6. Press the "T,F,S" softkey if you wish to view the "T,F,S" window.
The "T,F,S" window is displayed in the lower window of the left-
hand and right-hand channel column.
Note:
The "T,F,S" softkey is present only for smaller operator panels, i.e.
up to OP012.
Multi-channel view
11.2 Multi-channel view in the "Machine" operating area
Milling
674 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
