Closing the program
Press the ">>" and "Exit" softkeys to close the program and editor again.
- OR -
If you
are at
the start
of the
first line
of the
program, press
the <Cursor
left> key
to close the program and the editor.
To reopen a program you have exited with "Close", press the "Program" key.
Note
A program does not have to be closed in order for it to be executed.
Managing programs
14.2 Opening and closing the program
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
755
754
756
