Siemens MOBILETT Plus HP Maintenance Instruction

30 Inspection and Maintenance
MOBILETT Plus HP SPR8-220.101.04.03.02 Siemens AG
07.05 CS PS 24
Page 30 of 64
Medical Solutions
2.2.4 Brakes
Fig. 7:
SIM Uniformity
SIM Braking force
SIM Locking
• Check whether the hand brake is sufficient to stop the unit and that it does not pull to the
left or the right when applying the brake.
• Lock the brake.
¹ It should not be possible to push the MOBILETT using average force. Slight
skidding is permissible when applying a force greater than 350 N.
• Remove the upper, left and right covers and the cover with the cassette compartment.
• The brake force can be increased by increasing the tension on the brake cable
(Fig.7/p.30). Additional information can be found in the section on ”Adjustment of the
hand brake/parking brake” in the Service Instructions.
