Technical data
18 NXAIR / ≤ 40 kA 110-0134.9 / 14
4.10 Operating instructions for circuit-breaker type 3AE
For circuit-breakers type 3AE, separate operating instructions are available with detailed instructions and
information. The operating instructions are supplied as standard with every circuit-breaker type 3AE.
Additional operating instructions in different languages can be ordered at the regional Siemens
representative.
Fig. 4: Operating instructions for circuit-breaker type 3AE
Available operating instructions for circuit-breaker type 3AE:
Language
Order number of operating instructions
German
9229 0001 100 0F
Polish
9229 0001 155 0F
Russian
9229 0001 156 0F
Italian
9229 0001 172 0F
English
9229 0001 176 0F
French
9229 0001 177 0F
Spanish
9229 0001 178 0F
Portuguese
9229 0001 179 0F
Romanian
9229 0001 302 0F
4.11 Contactor type 3TL and 3TM
The vacuum contactor type 3TM3 is a 3-pole indoor contactor for ratings from 7.2 kV to 12 kV.
The vacuum contactor type 3TL8 is a 3-pole indoor contactor for ratings of 7.2 kV.
Available contactors type 3TL and 3TM depending on the design of the switchgear:
Panel width
[mm]
Rated voltage U
r
[kV]
3TM3
435
7.2
12
3TL8
600
7.2
