62/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
Fuse protection table for transformer panel NXPLUS C (HV HRC fuse-links make SIBA)
Order number of SIBA extension tube: 34 006 01 (Siemens part number: 02911500)
NOTICE
Use of HV HRC fuse-links with incorrect characteristic
Can damage the switchgear.
Do not use HV HRC fuse-links with different characteristics for nominally equal rated normal
current.
➭ Use exactly specified HV HRC fuse-links from the protection table.
System operating
voltage
Transformer HV HRC fuse-link
U
n
[kV] S
r
[kVA] u
k
[%] I
r
[A] I
r
[A] U
r
[kV] e [mm] Order No. SIBA Extension tube SIBA
3.3 … 3.6 20 4 3.5 6.3 3 … 7.2 292 30 098 13.6,3 X
10 3 … 7.2 292 30 098 13.10 X
3.3 … 3.6 30 4 5.25 10 3 … 7.2 292 30 098 13.10 X
16 3 … 7.2 292 30 098 13.16 X
3.3 … 3.6 50 4 8.75 16 3 … 7.2 292 30 098 13.16 X
20 3 … 7.2 292 30 098 13.20 X
3.3 … 3.6 75 4 13.1 20 3 … 7.2 292 30 098 13.20 X
25 3 … 7.2 292 30 098 13.25 X
3.3 … 3.6 100 4 17.5 31.5 3 … 7.2 292 30 098 13.31,5 X
40 3 … 7.2 292 30 098 13.40 X
3.3 … 3.6 125 4 21.9 31.5 3 … 7.2 292 30 098 13.31,5 X
40 3 … 7.2 292 30 098 13.40 X
3.3 … 3.6 160 4 28 40 3 … 7.2 292 30 098 13.40 X
50 3 … 7.2 292 30 098 13.50 X
3.3 … 3.6 200 4 35 50 3 … 7.2 292 30 098 13.50 X
63 3 … 7.2 292 30 099 13.63 X
3.3 … 3.6 250 4 43.7 63 3 … 7.2 292 30 099 13.63 X
80 3 … 7.2 292 30 099 13.80 X
3.3 … 3.6 315 4 55.1 80 3 … 7.2 292 30 099 13.80 X
100 3 … 7.2 292 30 099 13,100 X
3.3 … 3.6 400 4 70 100 3 … 7.2 292 30 099 13,100 X
4 … 4.8 20 4 2.9 6.3 3 … 7.2 292 30 098 13.6,3 X
4 … 4.8 30 4 4.4 10 3 … 7.2 292 30 098 13.10 X
4 … 4.8 50 4 7.3 16 3 … 7.2 292 30 098 13.16 X
4 … 4.8 75 4 11 16 3 … 7.2 292 30 098 13.16 X
20 3 … 7.2 292 30 098 13.20 X
4 … 4.8 100 4 14.5 20 3 … 7.2 292 30 098 13.20 X
25 3 … 7.2 292 30 098 13.25 X
4 … 4.8 125 4 18.1 25 3 … 7.2 292 30 098 13.25 X
31.5 3 … 7.2 292 30 098 13.31,5 X
4 … 4.8 160 4 23.1 31.5 3 … 7.2 292 30 098 13.31,5 X
40 3 … 7.2 292 30 098 13.40 X
4 … 4.8 200 4 28.7 40 3 … 7.2 292 30 098 13.40 X
50 3 … 7.2 292 30 098 13.50 X
4 … 4.8 250 4 36.1 50 3 … 7.2 292 30 098 13.50 X
63 3 … 7.2 292 30 099 13.63 X
4 … 4.8 315 4 45.5 63 3 … 7.2 292 30 099 13.63 X
80 3 … 7.2 292 30 099 13.80 X
4 … 4.8 400 4 57.8 80 3 … 7.2 292 30 099 13.80 X
100 3 … 7.2 292 30 099 13,100 X
4 … 4.8 500 4 72.2 100 3 … 7.2 292 30 099 13,100 X
5 … 5.5 20 4 2.3 6.3 3 … 7.2 292 30 098 13.6,3 X
5 … 5.5 30 4 3.4 6.3 3 … 7.2 292 30 098 13.6,3 X
10 3 … 7.2 292 30 098 13.10 X
