Installation
94/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
12.3 Transport units
Transport dimensions and transport weights
Center of gravity The center of gravity of NXPLUS C (all panels) is located at the following position:
The center of gravity is identified with the following symbol (arrow):
Ample AQT3-15/630 595 AHT3-15/630 495 - - - - - - - - - - - -
Solid-insulated
bar
Moser-Glaser 584 - - - - - - - - - - - - - - - - - -
Preissinger
Ritz
Make 1st/2nd cable 3rd/4th cable 5th/6th cable 7th/8th cable
Plug type Distance
[mm]
Plug type Distance
[mm]
Plug type Distance
[mm]
Plug type Distance
[mm]
Transport Panel spacing Transport dimensions
Width x Height x Depth
Transport weight [approx. kg]
1
1
Average value, depending on the degree to which the panel is equipped
[mm] [mm] x [mm] x [mm] with packing without packing
Rail or truck 1 x 450 1100 x 2460 x 1450 900 800
1 x 600 1100 x 2460 x 1450 900 800
1x 600 (top-rear cable
connection)
1100 x 2460 x 2100 900 800
1 x 900 1100 x 2460 x 1450
1300
2
/ 1500
2
Auxiliary transformer panel and air-insulated metering panel
1200
2
/ 1400
Auxiliary transformer 800 x 1200 x 1200 500 425
Ship or
airplane
1 x 450 1130 x 2550 x 1450 900 800
1 x 600 1130 x 2550 x 1450 900 800
1x 600 (top-rear cable
connection)
1130 x 2550 x 2100 900 800
1 x 900 1130 x 2550 x 1450
1300
2
/ 1500 1200
2
/ 1400
Auxiliary transformer 800 x 1200 x 1200 500 425
Position of the center of gravity
Panel width 600 mm Panel width 900 mm Panel width 600 mm and top-rear cable connection
①
Low-voltage compartment
②
Pressure relief duct
