Landis & Staefa Division CC1B7865E February 10, 2000 11/56
3. Installation
The front panel can be cleaned with normal washing and rinsing agents or detergents.
*
It is
not
resistant to corrosive acids, caustic solutions and abrasive cleaners, or
cleaning with high-pressure cleaners!
The controller module can be removed from the housing for servicing.
The rules of DIN EN 100 015 «Protection of electrostatically sensitive devices »
must be adhered to for internal work on the controller!
No liability
will be
accepted for damage caused by electrostatic discharge.
7865z09/0200
✱
✱✱
✱
Press the ribbed surfaces together (at top and bottom) and pull out the controller
module.
3.5. Cleaning the front panel
3.6 Removing the controller module
