3. Installation
−
The installation site should be as free as possible from vibrations, dust and corrosive
media
−
The controller should be installed as far away as possible from sources of
electromagnetic fields, such as frequency converters or high-voltage ignition
transformers
Relative humidity: < 95 % (non-condensing)
Ambient temperature range: -20...+50 °C
Storage temperature range: -40...+70 °C
48
96
91,5
K6
PGM
EXIT
RWF40
112
Panel cutout to DIN 43700
45
92
+0,6
+0,8
43,5
127,5
15,5
7865m01e/0200
3.1 Installation site and climatic conditions
3.2 Dimensions
