1. Introduction
The signs for
Danger
and
Caution
are used in this Manual under the following
conditions:
Danger
This symbol is used where there may be a
danger to personnel
if the instructions are
disregarded or not strictly followed!
*
Caution
This symbol is used where there may be
damage to equipment or data
if the
instructions are disregarded or not strictly followed!
Caution
This symbol is used if
pre-cautions must be taken
in handling electrostatically
sensitive components.
)
Note
This symbol is used to draw your
special attention
to a remark.
Ö
Reference
This symbol refers to
additional information
in other Manuals, chapters or sections.
abc¹
.
Footnote
Footnotes are
comments, referring to specific parts of the text.
They consist of two
parts:
1) The
markings
in the text are arranged as continuous superscript numbers
2) The
footnote text
is placed at the bottom of the page and starts with a number
and a period
✱
✱✱
✱
Action
This symbol indicates that
a required action
is described.
The individual steps are indicated by an asterisk, e.g.:
✱
✱✱
✱
Press the
▲
button
PGM
Buttons
Buttons are shown in a box. Either symbols or text are possible. If a button has multiple
assignments, the text shown is always the one that corresponds to the function
currently used.
EXIT
+
▲
Button
combi-
nations
The representation of buttons combined with a plus sign means that first the
EXIT
button must be pressed and held down and then the other button.
1.3 Typographical conventions
1.3.1 Warning symbols
1.3.2 Notification symbols
1.3.3 Presentation
