8. Configuration
*
The setting for the decimal place affects actual
value-dependent parameters!
0000
C113
7865p05/0200
Unit address
Address 0 0 0
Address 1 01
... ...
Address 99 99
Decimal places, dimensional unit
No decimal place, °C 0
One decimal place, °C 1
No decimal place, °F 2
One decimal place, °F 3
Signal for out-of-range
Limit comparators OFF 0
Limit comparators ON 1
Factory setting 0 1 1 0
8.3 C113 instrument address, dimensional unit, out-of-range
*
