Siemens RWF40 Series User Manual

Landis & Staefa Division CC1B7865E February 10, 2000 33/56
6. Operation
✱
✱✱
✱
Press
EXIT
for 5 s
The LED above the hand symbol lights up.
✱
✱✱
✱
Change the regulating unit’s position with
▲
and
▼
Relay 2 opens the regulating unit as long as
▲
is pressed.
Relay 3 closes the regulating unit as long as
▼
is pressed.
The LEDs for the regulating units indicate if «OPEN» or «CLOSE» is activated.
✱
✱✱
✱
Change the regulating unit’s position with
▲
and
▼
The modulating output delivers the regulating unit’s position that was entered.
✱
✱✱
✱
Return to automatic operation by pressing
EXIT
for 5 s
)
When manual operation is activated, the regulating unit’s position is set to 0
until another entry with the buttons is made.
Manual operation can only be activated if the thermostat function has set relay 1 to
active
.
If the thermostat function sets relay 1 to
inactive
during manual operation, manual
operation is terminated.
✱
✱✱
✱
Press
EXIT
for 5 s
✱
✱✱
✱
Press
▲
briefly
−
Relay 2 is active, relay 3 is inactive
−
Analog output (optional) delivers DC 10 V
The regulating unit opens
✱
✱✱
✱
Or press
▼
briefly
−
Relay 2 is inactive, relay 3 is active
−
Analog output (optional) delivers DC 0 V
The regulating unit closes
✱
✱✱
✱
Return to automatic operation by pressing
EXIT
for 5 s
)
If the thermostat function sets relay 1 to
inactive
during manual operation,
manual operation is terminated.
6.2.2 Manual operation, modulating burner
3-position controller
Modulating controller
Thermostat mode
6.2.3 Manual operation, two-stage burner
