Siemens RX1400 - Getting YIN and YANG Files from the Device

RUGGEDCOM NETCONF
Reference Guide
Chapter 4
Getting Data
Getting YIN and YANG Files from the Device 37
3. Review the list and locate the <schema> entries for items you want to retrieve. For example, shown here are
the <schema> entries for the rmf_admin namespace:
<schema>
<identifier>rmf_admin</identifier>
<version>2012-03-07</version>
<format>yin</format>
<namespace>http://ruggedcom.com/ns/rmf_admin</namespace>
<location>NETCONF</location>
</schema>
<schema>
<identifier>rmf_admin</identifier>
<version>2012-03-07</version>
<format>yang</format>
<namespace>http://ruggedcom.com/ns/rmf_admin</namespace>
<location>NETCONF</location>
</schema>
4. Make a note of the <identifier>, <format>, and <version> data. You need this information to retrieve
the YIN or YANG file from the device.
5. After finding the <identifier>, <format>, and <version> for the schema you want to download, you
can retrieve the YIN and YANG files. For instructions, refer to Section4.6.2, “Getting YIN and YANG Files from
the Device”.
Section4.6.2
Getting YIN and YANG Files from the Device
To retrieve a specific YIN or YANG file, do the following:
1. Log in to the device and start a NETCONF session. For instructions on how to initiate a NETCONF session, refer
to Section3.2, “Connecting to the NETCONF Service”.
2. Download a list of schemas from RUGGEDCOM NETCONF and determine the identifier, version and format of
the schema associated with the target YIN or YANG file. For more information, refer to Section4.6.1, “Getting
Schemas from the Device”.
3. Issue this command:
<rpc message-id="101" xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<get-schema xmlns="urn:ietf:params:xml:ns:yang:ietf-netconf-monitoring">
<identifier>{identifier}</identifier>
<version>{version}</version>
<format>{format}</format>
</get-schema>
</rpc>]]>]]>
• {identifier}
Specifies the schema name.
• {version}
Specifies the schema version number.
• {format}
Specifies the schema format: yin or yang.
For example, this command retrieves the rmf_admin YIN file:
<rpc message-id="101" xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<get-schema xmlns="urn:ietf:params:xml:ns:yang:ietf-netconf-monitoring">
<identifier>rmf_admin</identifier>
