Configuring with Web Based Management
6.5 "System" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
199
File type
Description
Save
Down-
load
Script Text file with CLI commands
You can upload a script file in a device. The CLI
commands it contains are executed accordingly.
CLI commands for saving and loading files cannot be
executed with the CLI script file.
-- X
StartupInfo Startup log file
This file contains the messages that were entered in
the log file during the last startup.
X --
Users
File with user names and passwords
X
X
WBMFav WBM favorites
This file contains the favorites that you created in the
WBM. You can download this file and upload it to
other devices.
X X
WLANAuthlog File with entries from the WLAN Authentication Log
(information on successful or failed authentication
attempts)
X --
WLANCert
(in client mode only)
User certificate. You can specify a password for the
user certificate on the WBM page "Load&Save >
Password".
Maximum file size: 8192 bits
X X
WLANServerCert
(in client mode only)
Server certificate
Maximum file size: 8192 bits
X X
WLANSigRec
(in client mode only)
The zip file contains the following:
• csv file with the measured values of the signal
recorder
• pdf file with the measured values and an addition-
al graphic representation of the measured values.
You will find information about the measured values
and their graphic representation in the section "Signal
recorder (Page 305)".
X --
WLANSpectru-
mAnalyzer
(Only in access
point mode)
The Zip file contains a csv file with the measured
values of the spectrum analyzer.
You will find information about the measured values
and their graphic representation in the section
"Spectrum analyzer (Page 316)".
X --
