Technical basics
4.10 AeroScout
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
66 Configuration Manual, 08/2018, C79000-G8976-C267-13
SCALANCE W700 devices support tags of the AeroScout company. Tags are battery-
operated RFID sensors that send their data cyclically as multicast frames.
Among other things, AeroScout tags have the following features:
●
If a tag is fitted to a SCALANCE W700 device or material, it is possible to monitor
whether a selected ambient temperature is being maintained.
●
Here, a tag can also supply information indicating whether it is in motion or stationary.
The areas of material flow and material handling engineering represent possible
applications for this function.
●
Regardless of the frames sent cyclically, a user can also send a message by pressing a
button.
●
This provides information on the operating status of the tag.
Note
For more detailed information, please refer to the AeroScout documentation
(www.aeroscout.com).
The tag sends its data as AeroScout frames. The tags and the access points communicate
in the 2.4 GHz band.
If the WLAN interface of the access point receives the AeroScout frame, this is converted
into a UDP datagram. The SCALANCE W700 device forwards the UDP datagram along with
the information about the signal strength (RSSI) to a PC. The AeroScout Engine runs on the
PC and evaluates the received information.
advisable to use PROFINET communication and AeroScout together on one
