Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
173
The table has the following columns:
●
Shows the VAP interface to which the entries apply.
●
The other columns after the VAP interface contain the absolute numbers of the received
frames according to the frame types.
In the columns of the table, a distinction is made according to the following frame types:
– Data Frames
Shows the number of sent data frames.
– Multicast/Broadcast Frames
Shows the number of sent multicast and broadcast frames.
– Unicast Frames
Shows the number of sent unicast frames.
– Average Data Rate
Shows the average data rate of the last data frames sent.
The WBM page shows the antenna connector via which the clients logged on to the access
point communicate. Other information such as the signal strength and the MAC address of
the WLAN interface is also shown.
This WBM page is only available in access point mode.
This WBM page can only be configured with the following KEY-PLUG:
Access point: W780 iFeatures (MLFB 6GK5 907-8PA00)
