Configuring with Web Based Management
6.7 "Layer 2" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
327
6.7
"Layer 2" menu
6.7.1
VLAN
6.7.1.1
General
VLAN configuration page
On this page you specify whether or not the device forwards frames with VLAN tags
transparently (IEEE 802.1D/VLAN-unaware mode) or takes VLAN information into account
(IEEE 802.1Q/VLAN-aware mode). If the device is in the "802.1Q VLAN Bridge" mode, you
can define VLANs and specify the use of the ports .
Note
Changing the agent VLAN ID
If the configuration PC is connected directly to the device via Ethernet and you change the
agent VLAN ID, the device is no longer reachable via Ethernet following the change.
