Configuring with Web Based Management
6.7 "Layer 2" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
334 Configuration Manual, 08/2018, C79000-G8976-C267-13
6.7.3
Spanning Tree
6.7.3.1
General
General settings of spanning tree
This is the basic page for spanning tree. Select the compatibility mode from the drop-down
list. As default, Multiple Spanning Tree is enabled.
On the configuration pages of these functions, you can make detailed settings.
Depending on the compatibility mode, you can configure the corresponding function on the
relevant configuration page.
Note
Client device not as root
Using the configuration of priorities and path costs, make sure that a client device can never
become the root node. If a client
device becomes the root node the Rapid Spanning Tree
function no longer works.
