Configuring with Web Based Management
6.5 "System" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
257
Note
Devices with two Ethernet ports
On devices with two Et
hernet interfaces only one of the interfaces (P1 or P2) may be used
for the Ethernet configuration.
This applies to the following devices:
•
SCALANCE W786-2 SFP
•
SCALANCE W774-1 RJ45
•
SCALANCE W774-1 M12 EEC
•
SCALANCE W778-1 M12
•
SCALANCE W778-1 M12 EEC
•
SCALANCE W734-1 RJ-45
•
SCALANCE W738-1 M12
Description
The page contains the following boxes:
●
EtherNet/IP Device Diagnostics
Shows whether EtherNet/IP is enabled ("On") or disabled ("Off").
●
EtherNet/IP Device Diagnostics for next boot
Set whether EtherNet/IP will be enabled ("On") or disabled ("Off") after the next device
restart.
Note
EtherNet/IP and PROFINET
When EtherNet/IP is turned on, PROFINET is turned off. The switchover from EtherNet/IP
and PROFINET has no effect on DCP.
Note
PROFINET AR Status
If a PROFINET connection is established; in other words the PROFINET AR status is
"Online", you cannot enable EtherNet/IP.
