Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
304 Configuration Manual, 08/2018, C79000-G8976-C267-13
Description
Table 1 is only available in access point mode and is divided into the following columns:
Radio
Shows the available WLAN interfaces.
Force roaming on link down
When enabled if there is a connection abort via the Ethernet interface, the WLAN
interface is turned off.
The table "Force Roaming on IP down"has the following columns:
Select
Select the check box in the row to be deleted.
Destination Address
Enter the IPv4 address or the FQDN (Fully Qualified Domain Name) of the destination
whose reachability will be checked.
Note
Destination address not in the agent IP subnet
If the destination address is n
ot in the agent IP subnet, a gateway must be entered for
"Layer 2 > Agent IP".
The Base Bridge mode "802.1Q VLAN Bridge"
If you have configured the "Based Bridge Mode" "802.1Q VLAN Bridge" in "Layer 2 >
VLAN", pings are sent into the management VLAN.
Interval [ms]
Specify the interval at which pings are sent.
Max. Lost Packets
Specify the maximum number of consecutive lost ping responses. When this number is
reached for a destination address, this destination address counts as being unreachable
(down).
VAP X.Y
(in access point mode)
Specify which VAP interface will be monitored.
WLAN
0/X (in client mode)
Specify which WLAN interface will be monitored.
