Appendix
A.1 Modbus
136
PAC3120 and PAC3220
Equipment Manual, 10/2019, L1V30425208F-01
A.1.8 Modbus communication parameters with the function codes 0x03, 0x04 and
0x10
Addressing the communication parameters
Table A- 11 Addressing the communication parameters
Offset
Number of
registers
Name
Format
Value range
Access
62983 2 Aggregation file 1
(period length)
Unsigned
long
> 3 s RW
62985 2 Aggregation file 1
(method)
Unsigned
long
0 = AUTO
1 = RMS
2 = ARITHMETIC
RW
62987 2 Aggregation file 2
(period length)
Unsigned
long
Preferred integer mul-
tiplier of stage (−1)
period length
Integer divider of a
minute, or an hour or a
day
RW
62989 2 Aggregation file 2
(method)
Unsigned
long
0 = AUTO
1 = RMS
2 = ARITHMETIC
RW
62991 2 DHCP ON/OFF
2)
Unsigned
long
0 … 1 RW
62993 2 SNTP server IP address
2)
Unsigned
long
0 … 0xFFFFFFFF RW
62995 2 SNTP mode
2)
Unsigned
long
0 = SNTP client OFF
1 = SNTP active client
2 = SNTP broadcast
client
RW
62999 2 IP port number
2)
Unsigned
long
1 … 0xFFFF RW
63001 2 IP address
2)
Unsigned
long
0 … FFFFFFFFh RW
63003 2 Subnet
2)
Unsigned
long
0 … FFFFFFFFh RW
63005 2 Gateway Unsigned
long
0 … FFFFFFFFh RW
63019 2 Modbus address
1)
Unsigned
long
1 … 247 RW
63021 2 Baud rate
1)
Unsigned
long
0 = 4800 baud
1 = 9600 baud
2 = 19200 baud
3 = 38400 baud
4 = 57600 baud
5 = 115200 baud
RW
