Parameter assignment
7.2 Parameterizing via the operator interface
PAC3120 and PAC3220
Equipment Manual, 10/2019, L1V30425208F-01
73
Current input
Selection
Range
Factory setting
CT PRIMARY Primary current of the current transformers
1 … 99999 A
50 A
CT SECONDARY Secondary current of the current transformers
• 1 A
• 5 A
5 A
DISPLAY RANGE: Freely adjustable
1 … 99999 A
50 A
• CURRENT DIREC L1
• CURRENT DIREC L2
• CURRENT DIREC L3
Inverse evaluation of the current flow direction
separately for each phase.
• ON: Direction of current flow is inverted.
The device interprets the current flow direc-
tion as opposite to the wiring.
• OFF: The device interprets the current
flow direction to match the wiring.
OFF
7.2.4 Date/time
Setting the date and time
Selection
Range
Factory setting
DATE Current date.
The date format is defined in the FORMAT field.
–
FORMAT
• DD.MM.YYYY
• YYYY-MM-DD
• MM/DD/YY
DD.MM.YYYY
TIME
HH:MM:SS
–
TIME ZONE Time zone, refers to coordinated universal time
(UTC).
−12:00 … +14:00, in 30-minute intervals
Examples:
• "−06:00" corresponds to UTC-6
• "+01:00" corresponds to UTC+1
00:00
