Appendix
A.1 Modbus
PAC3120 and PAC3220
Equipment Manual, 10/2019, L1V30425208F-01
141
File
(FC0x14)
Offset
Address
Address
FC 0x03
FC 0x04
Length
Name
Format
Access
1
67
30067
2
VA_SUM
Float
R
1
69
30069
2
P_SUM
Float
R
1
71
30071
2
VARQ1_SUM
Float
R
1 73 30073 2 PF_SUM Float R
1
75
30075
2
V_BAL
Float
R
1
77
30077
2
I_BAL
Float
R
1
79
30079
2
I_N
Float
R
1
257
30257
2
Time stamp aggregation stage n
UNIX_TS
R
1
259
30259
2
Flags aggregation stage n
Uint32
R
1
261
30261
2
max_V_L1
Float
R
1
263
30263
2
max_V_L2
Float
R
1
265
30265
2
max_V_L3
Float
R
1
267
30267
2
max_V_L12
Float
R
1
269
30269
2
max_V_L23
Float
R
1
271
30271
2
max_V_L31
Float
R
1
273
30273
2
max_I_L1
Float
R
1
275
30275
2
max_I_L2
Float
R
1
277
30277
2
max_I_L3
Float
R
1
279
30279
2
max_VA_L1
Float
R
1
281
30281
2
max_VA_L2
Float
R
1
283
30283
2
max_VA_L3
Float
R
1
285
30285
2
max_P_L1
Float
R
1 287 30287 2 max_P_L2 Float R
1
289
30289
2
max_P_L3
Float
R
1 291 30291 2 max_VARQ1_L1 Float R
1
293
30293
2
max_VARQ1_L2
Float
R
1
295
30295
2
max_VARQ1_L3
Float
R
1
297
30297
2
max_PF_L1
Float
R
1
299
30299
2
max_PF_L2
Float
R
1
301
30301
2
max_PF_L3
Float
R
1
303
30303
2
max_THDV_L1
Float
R
1
305
30305
2
max_THDV_L2
Float
R
1
307
30307
2
max_THDV_L3
Float
R
1
309
30309
2
max_THDI_L1
Float
R
1
311
30311
2
max_THDI_L2
Float
R
1
313
30313
2
max_THDI_L3
Float
R
1
315
30315
2
max_FREQ
Float
R
1
317
30317
2
max_V_LN_AVG
Float
R
1
319
30319
2
max_V_LL_AVG
Float
R
1
321
30321
2
max_I_AVG
Float
R
