Parameter Settings
69
Overcurrent
Alarm Settings
% I
n
115% 125% 150% 200% 250%
I
n
= Rating
Plug (A)
Pickup (A)
200 230 250 300 400 500
225 258 281 337 450 562
250 287 312 375 500 625
300 345 375 450 600 750
350 402 437 525 700 875
400 460 500 600 800 1000
450 517 562 675 900 1125
500 575 625 750 1000 1250
600 690 750 900 1200 1500
700 805 875 1050 1400 1750
800 920 1000 1200 1600 2000
1000 1150 1250 1500 2000 2500
1200 1380 1500 1800 2400 3000
1600 1840 2000 2400 3200 4000
2000 2300 2500 3000 4000 5000
2500 2875 3125 3750 5000 6250
3000 3450 3750 4500 6000 7500
3200 3680 4000 4800 6400 8000
4000 4600 5000 6000 8000 10000
5000 5750 6250 7500 10000 12500
Max Rating (A)
Ground Fault Protection Pickup Settings
and
Ground Overcurrent Alarm Settings
Pickup (A)
400 80 100 120 160 200 240 280 320 360 400
800 160 200 240 320 400 480 560 640 720 800
1200 240 300 360 480 600 720 840 960 1080 1200
1600 320 416 512 608 704 800 896 992 1088 1200
2000 400 460 540 600 700 800 900 1000 1100 1200
2500 500 575 650 725 800 875 950 1025 1100 1200
3200 640 672 736 800 864 928 992 1056 1120 1184
4000 800 840 880 920 960 1000 1040 1080 1120 1200
5000 1200
