Parameter Settings
70
Neutral Overcurrent
Relay Settings
% Max Rating 115% 125% 150% 200% 250%
Max Rating
(A)
Pickup (A)
400 460 500 600 800 1000
800 920 1000 1200 1600 2000
1200 1380 1500 1800 2400 3000
1600 1840 2000 2400 3200 4000
2000 2300 2500 3000 4000 5000
2500 2875 3125 3750 5000 6250
3200 3680 4000 4800 6400 8000
4000 4600 5000 6000 8000 10000
5000 5750 6250 7500 10000 12500
Overcurrent Demand
Alarm Settings
% I
n
60% 70% 80% 90% 95% 100%
I
n
= Rating Plug
(A)
Pickup (A)
200 120 140 160 180 190 200
225 135 157 180 202 213 225
250 150 175 200 225 237 250
300 180 210 240 270 285 300
350 210 245 280 315 332 350
400 240 280 320 360 380 400
450 270 315 360 405 427 450
500 300 350 400 450 475 500
600 360 420 480 540 570 600
700 420 490 560 630 665 700
800 480 560 640 720 760 800
1000 600 700 800 900 950 1000
1200 720 840 960 1080 1140 1200
1600 960 1120 1280 1440 1520 1600
2000 1200 1400 1600 1800 1900 2000
2500 1500 1750 2000 2250 2375 2500
3000 1800 2100 2400 2700 2850 3000
3200 1920 2240 2560 2880 3040 3200
4000 2400 2800 3200 3600 3800 4000
5000 3000 3500 4000 4500 4750 5000
