Table B-12 Date and Time – Seconds
Bit 15 14 13 12 11 10 9 8
Milliseconds
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Milliseconds
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Range 0 to 59999 ms
Default 0
(Address 6)
Table B-13 Date and Time – Hours/Minutes
Bit 15 14 13 12 11 10 9 8
Not used Not used Not used Hours
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Minutes
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Hours Format 5-bit unsigned integer
Unit h
Range 0 to 23
Minutes Format 6-bit unsigned integer
Unit Min
Range 0 to 59
(Address 7)
Table B-14
Date and Time – Date/Month
Bit 15 14 13 12 11 10 9 8
Not used Month
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Date
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Month
Format 4-bit unsigned integer
Unit Month
Range 1 to 12
Date Format 5-bit unsigned integer
Unit Date
Range 1 to 31
(Address 8)
Modbus Registers
B.4 Register-Type Data – Holding Registers
