Siemens SICAM User Manual

Register-Type Data – Analog Input Registers
Last Reset Type
(Address 1) This register contains the last reset type.
Bit 15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Auto (self)
reset
Modbus
reset
User inter-
face reset
BI reset Not used
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit –
Range –
Last Reset Time (Milliseconds)
(Address 2) This register contains the last reset time in milliseconds.
Bit 15 14 13 12 11 10 9 8
Milliseconds
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Milliseconds
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit ms
Range 0 to 59999
Last Reset Time (Hours and Minutes)
(Address 3) This register contains the last reset time in hours and minutes.
Bit
15 14 13 12 11 10 9 8
Hours
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Minutes
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 8-bit unsigned integer
Unit h
Range 0 to 23
Format 8-bit unsigned integer
Unit min
Range 0 to 59
Last Reset Time (Month and Date)
(Address 4) This register contains the last reset time in month and date.
B.6
Modbus Registers
B.6 Register-Type Data – Analog Input Registers
144 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019

Siemens SICAM Specifications

General

Measurement Accuracy	±0.1%
Input Current Range	0-5A AC/DC
Frequency Range	45-65Hz
Communication Interfaces	Ethernet, RS485
Power Supply	24 V DC
Protection Class	IP20
