Bit 15 14 13 12 11 10 9 8
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit s
Range 0, 30 to 240
Default 0
I
Max
Alarm
(Address 34) This register defines the overcurrent alarm. The value is expressed in amperes.
Bit 15 14 13 12 11 10 9 8
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit A
Range 50 to 2000
Default 0
When 0 is selected, then the I
max
alarm is disabled.
I
Max
Warning
(Address 35) This register defines the overcurrent warning. The value is expressed in amperes.
Bit
15 14 13 12 11 10 9 8
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit A
Range 50 to 2000
Default 0
When 0 is selected, then the I
max
warning is disabled.
I
Max
Alarm Time Setting
(Address 36) This register defines the overcurrent alarm time. The value is expressed in minutes.
Bit
15 14 13 12 11 10 9 8
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Unit min
Range 1 to 120
Default 0
Modbus Registers
B.4 Register-Type Data – Holding Registers
