Siemens SICAM - Mechanical and EMC Tests

Mechanical Tests
Table 6-4 Mechanical Tests
Tests Standards Test Requirements
Vibration response
test
IEC 60068-2-6, Class I Sinusoidal
10 Hz to 150 Hz: ± 0.035 mm amplitude, 0.5 g acceleration,
frequency sweep rate 1 octave/min, 1 cycle in 3 orthogonal
axes
Vibration withstand
test
IEC 60068-2-6, Class I Sinusoidal
10 Hz to 150 Hz: ± 0.075 mm amplitude, 1 g acceleration,
frequency sweep rate 1 octave/min, 20 cycles in 3 orthog-
onal axes
Shock response test IEC 60068-2-27, Class I Acceleration 5 g, duration 11 ms, 18 shocks each in both
directions of the 3 orthogonal axes
Shock withstand test IEC 60068-2-27, Class I Acceleration 15 g, duration 11 ms, 18 shocks each in both
directions of the 3 orthogonal axes
EMI/EMC Tests for Immunity
Table 6-5 Immunity Test
Test Standards Test Requirements
Electrostatic
discharge immunity
test
IEC 61000-4-2, Level 3 8 kV air discharge and 6 kV contact discharge
Electromagnetic high
frequency distur-
bance (Radiated
Susceptibility Test)
IEC 61000-4-3, Level 3 80 MHz to 1 GHz (10 V/m, Criteria B) and
1.4 GHz to 2.7 GHz (10 V/m, Criteria B)
Electrical fast tran-
sient/burst immunity
test
IEC 61000-4-4, Level 3 ± 4 kV on auxiliary power supply, current inputs, voltage
inputs, digital input, and digital outputs
± 2 kV on communication port
Surge immunity test IEC 61000-4-5, Level 3
IEC 61326-1, Level 3
± 2 kV DM, ± 4 kV CM on auxiliary power supply and
voltage inputs
± 1 kV DM, ± 2 kV CM on digital input and digital outputs
± 4 kV on current inputs
± 2 kV on communication port
Conducted suscepti-
bility test
IEC 61000-4-6, Level 2
IEC 61326-1, Level 2
150 kHz to 80 MHz (3 V) on auxiliary power supply, current
inputs, voltage inputs, digital input, digital outputs, and
communication port
Damped oscillatory
wave immunity test
IEC 61000-4-18, Level 3 2.5 kV (CM), 1.0 kV (DM) applied on current inputs, voltage
inputs, digital input, digital outputs, and communication
port
(1 MHz, 100 kHz)
Power frequency
magnetic field
IEC 61000-4-8, Level 4 30 A/m (continuous field) and 300 A/m pulsed (short dura-
tion for 3 s) on the X, Y, Z axis of the product
Voltage dips and
interruptions
IEC 61000-4-11,
IEC 61000-4-29,
IEC 61326-1
0 %, 40 %, and 70 % dips on AC/DC power supply
0 % short interruptions for 250/300 cycles (50 Hz/60 Hz)
Type Testing
6.1 Type Testing
SICAM, Feeder Condition Monitor, Manual 67
E50417-H8940-C580-A4, Edition 03.2019
