Siemens Sicore II

System Components
Sicore II Installation and Commissioning Guide
667/HB/52600/000 Issue 2 Unrestricted
31
Figure 8 – Example screen clamp arrangement
Cores
Ident
Stud
Nut
CETBar
Cable Sheath
Incoming Cable
SIDE VIEW
Earthing Band
667/2/02348/000
Wormdrive Hose Clip
991/4/01375/028
PLAN VIEW
(Screen not shown at
front of ring for clarity)
