Installation
Sicore II Installation and Commissioning Guide
667/HB/52600/000 Issue 2 Unrestricted
48
In summary for installation and alignment the critical values required to be determined are:
Height (H) – Height of camera above road surface
Distance D (D) – Distance along the side of the road from the camera to the centre
of the capture zone
Skew (S) Distance from the camera at the side of the road measured to the
centre of the capture zone
Parameter Description Default or result value
W Width of the street or lane to be
captured (at road surface)
Result value: Width of capture zone
measured at the road surface.
W1 Width of the street or lane to be
captured (at plate height)
Result value : Either two lane (7.8m) or
three lane (9.5m) note that these
values are at the licence plate height.
H Mounting height of Sicore above
road surface
Default value
D Distance from Sicore to the
horizontal centre line within the
image area
Result value : Take from table
V Depth of View Result value : Take from table
V1 Distance to start of Field of View
from Camera
Result value : Take from table
b Camera Angle for horizontal Result value : Take from table
F focal length 12.5, 16, 25 or 35mm for IR camera
DCN Distance Camera to Number plate
(calculated assuming a plate
50cm above the ground)
Result value : Take from table (driven
by height and skew)
DCS Distance Camera to Street Result value : Take from table (driven
by height and skew)
S Horizontal Shift Default Value : Driven by pole position
and skew to centre of capture zone
Table 14 - Geometry Acronyms
