Siemens Sicore II

Installation
Sicore II Installation and Commissioning Guide
667/HB/52600/000 Issue 2 Unrestricted
49
Two lane application – Nominal 7.8m capture width at plate height
W
[m]
W1
[m]
H
[m]
D
[m]
V
[m]
V1
[m]
b
[deg]
f
[mm]
DCS
[m]
DCN
[m]
S
[m]
Max
angle
check
[Deg]
9.4 7.8 3 10 169.1 4.7 16.7 12.5 10.4 8.7 0 30
9.4 7.8 3 9.7 173.9 4.7 16.7 12.5 10.5 8.7 2.5 40
9.4 7.8 3 13 279.7 6.3 13 16 13.3 11.1 0 24
9.3 7.8 3 12.3 252.2 6.3 13.1 16 13.3 11.1 4 37
8.9 7.8 4 9.1 23.5 4.9 23.7 12.5 9.9 8.7 0 35
9 7.9 4 8.8 23.9 4.9 23.6 12.5 10 8.7 2.5 44
8.9 7.8 4 12 31.1 6.7 18.4 16 12.6 11.1 0 27
8.9 7.8 4 11.3 31 6.7 18.5 16 12.6 11.1 4 41
9 7.9 4 19.6 53.6 11.3 11.5 25 20 17.5 0 17
9 7.9 4 17.9 53.7 11.3 11.5 25 20 17.5 8 37
8.9 7.8 4 27.5 74.2 16 8.3 35 27.8 24.3 0 12
8.9 7.8 4 23.7 74.4 16 8.3 35 27.8 24.3 14 39
8.7 7.8 5 11.3 17.8 6.8 23.9 16 12.4 11.1 0 31
8.6 7.8 5 10.5 17.6 6.8 24 16 12.3 11.1 4 44
8.8 7.9 5 18.8 29.6 11.8 14.9 25 19.5 17.5 0 20
8.7 7.9 5 17 29.5 11.8 14.9 25 19.4 17.5 8 39
8.7 7.8 5 26.5 40.8 17 10.7 35 27 24.3 0 14
8.7 7.8 5 22.5 40.8 17 10.7 35 27 24.3 14 40
8.5 7.8 6 10.5 12.6 6.6 29.7 16 12.1 11.1 0 36
8.6 7.9 6 18.1 20.8 12.1 18.3 25 19.1 17.5 0 23
8.6 7.9 6 16.3 20.9 12.1 18.3 25 19.1 17.5 8 41
8.5 7.8 6 25.8 28.9 17.6 13.1 35 26.5 24.3 0 16
8.5 7.8 6 21.7 28.9 17.6 13.1 35 26.5 24.3 14 42
8.5 7.9 7 17.5 16.3 12.2 21.8 25 18.8 17.5 0 26
8.5 7.9 7 15.6 16.3 12.2 21.8 25 18.9 17.5 8 43
8.4 7.8 7 25.2 22.6 18 15.5 35 26.2 24.3 0 18
8.4 7.8 7 21 22.7 18 15.5 35 26.2 24.3 14 43
8.4 7.9 8 16.9 13.5 12.2 25.3 25 18.7 17.5 0 29
8.4 7.9 8 14.9 13.5 12.2 25.3 25 18.7 17.5 8 46
8.3 7.8 8 24.7 18.7 18.2 17.9 35 26 24.3 0 20
8.3 7.8 8 20.3 18.7 18.2 18 35 25.9 24.3 14 45
Table 15 – Two lane Geometry
