System Components
Sicore II Installation and Commissioning Guide
667/HB/52600/000 Issue 2 Unrestricted
Aux 1 connector on Sicore
unit (view from mating
side )
19-way male circular
connector (ITT Cannon)
Connector pins, view from
mating side
Figure 10 – Aux 1 Connector Pin Arrangement
When the Aux interface connectors are not used the supplied connector
covers MUST be fitted to protect the contact area from dirt and corrosion
