Interrupts/diagnostic messages
6.3 Diagnostic messages
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
Manual, 08/2018, A5E41448857-AB
61
Diagnostic message
Fault
code
Meaning
Remedy
Channel failure acknowl-
edgment
30B
H
A channel fault was detected. Confirma-
tion is required to enable the channel.
Confirm the channel fault.
No valid F-address available 30D
H
The F-source address and F-destination
address stored in the electronic coding
element cannot be accessed.
Verify that the coding element is pre-
sent. Replace the coding element, if
necessary.
F-address memory not ac-
cessible
30E
H
No valid PROFIsafe address is saved in
the retentive memory.
Possible causes:
• Initial commissioning
• Deliberate parameter change of the
PROFIsafe address
• Deviation between target and actual
configuration of the plant.
• In the case of initial commissioning
or deliberate parameter change,
assign the PROFIsafe address.
• Check the consistency of the target
and actual configuration.
Undertemperature 312
H
The minimum permissible temperature
limit has been violated.
Operate the F-module within the speci-
fied temperature range (see Technical
specifications (Page 64))
Discrepancy error 314
H
The discrepancy time set for 1oo2 opera-
tion has been exceeded.
Possible causes of the discrepancy error:
• Incorrect parameter assignment
• Wire break in the sensor's supply
cable
Check the discrepancy time, the sen-
sors and the cabling.
Read back failure 31E
H
The F-module detected an internal error
in the test connection.
Possible causes:
• Increased EMC
• F-module defective
If the error persists, replace the F-
module.
Auxiliary voltage too high 321
H
The supply voltage is too high. Check the supply voltage and then test
the safety application.
Auxiliary voltage too low 322
H
The supply voltage is too low. Check the supply voltage and then test
the safety application.
ADC error 331
H
Internal error during analog-digital con-
version.
Possible causes:
• Increased EMC
• F-module defective
If the error persists, replace the F-
module.
Fault in test connection 332
H
The F-module detected an internal error
in the test connection.
Possible causes:
• Increased EMC
• F-module defective
If the error persists, replace the F-
module.

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
